Particles Plus 5301-AQM1 Fixed Air Quality Monitor

$0.00

The Particles Plus 5301-AQM1 is a state-of-the-art fixed remote particle monitor designed for online continuous particle / dust measurements for many different indoor air quality applications. These feature packed remote sensors are also capable of measuring temperature, humidity and CO2 logging this data and transmitting it back to BMS, EMS, SCADA systems or data collection websites.

The Particles Plus 5301-AQM1 boasts many advanced features way of beyond the capabilities of many competitive instruments on the market. The long battery life, massive data storage, multi-channel mass (mg/m3) measurement capabilities, advanced communication options and other key features make this a very powerful and useful instrument for continuous monitoring across many different industries.

Description

The Particles Plus 5301-AQM1 is a state-of-the-art fixed remote particle monitor designed for online continuous particle / dust measurements for many different indoor air quality applications. These feature packed remote sensors are also capable of measuring temperature, humidity and CO2 logging this data and transmitting it back to BMS, EMS, SCADA systems or data collection websites. The Particles Plus 5301-AQM1 boasts many advanced features way of beyond the capabilities of many competitive instruments on the market. The long battery life, massive data storage, multi-channel mass (mg/m3) measurement capabilities, advanced communication options and other key features make this a very powerful and useful instrument for continuous monitoring across many different industries.

Measurement Capabilities

  • Counts and sizes particles over 6 particle size channels from 300nm to 25um
  • Simultaneous PM mass fraction dust measurements
  • Measures temperature from 0 to 50 degrees C with +/- 0.5 deg C accuracy
  • Measures humidity from 15% to 90% with 2% RH accuracy
  • Measures barometric pressure
  • Measures CO2 from 0 to 5,000ppm with 1ppm accuracy

particles plus 5301-aqm1

Key Features

  • 0.3um to 25um wide particle size range
  • 2.83 LPM (0.1 CFM) flow rate with built-in pump and automatic flow control
  • 6 simultaneous particle size channels (0.3um, 0.5um, 1.0um, 2.5um, 5.0um, 10.0um)
  • 6 simultaneous PM dust fractions (PM0.3, PM0.5, PM1.0, PM2.5, PM5, PM10)
  • 0.001 to 20mg/m3 particle mass measurement range
  • Incredible 0.00003ug/m3 resolution
  • Particle density and refractive index correction capabilities
  • FREE Instrument Management Software (IMS)
  • User selected particle size channels
  • Massive 45,000 sample data storage
  • The latest long-life laser diode technology
  • Large easy to use icon driven WQVGA 480 x 272 color touch screen display
  • Remote diagnostics allows for remote service investigation through the Internet
  • Easy configuration and transferable from instrument to instrument
  • Connect using Ethernet, USB or (optional) Wireless 802.11 b/g, RS 485 or RS232
  • Internal audible alarm with user selected thresholds for all environmental parameters
  • Internal HEPA filter for pump exhaust
  • Lightweight stainless steel enclosure
  • Made in the USA
  • NIST traceable calibration certificate included
  • Easily installed and setup by the end user
  • 110 VAC to 240 VAC power supply
  • 2 year limited warranty

The Particles Plus 5301-AQM2 is one instrument in a wide range of latest generation dust and particle monitoring instruments available from Alpha Scientific. Alpha Scientific also supplies aerosol diluters and many other particle measurement options and accessories.

Specifications

https://particlesplus.com/5301-iaq-remote-particle-counter/

Downloads

Product Brochure: Particles-Plus-5301-AQM1-5301-AQM2-Datasheet
