Description
The SFP Services 4000 sodium chloride aerosol generator is an atomizer which is used in the SFP Services 1100 bench-mounting rig and is described in EN143. It is a compact unit, using a 1 liter commercially available glass jar (reservoir) and removable nozzle for easy maintenance. A 0.5 liter jar (reservoir) for atomizing small quantities of solutions as used in microbiology is also available.
Dimensions
- 230 high x 90 wide x 90 mm deep. [1.0 liter]
- 170 high x 90 wide x 90 mm deep. [0.5 liter]
Air Supply
- 13 liters/minute @ 3.45 bar
Aerosol Size
- Used with Na Cl solution 0.6 µm MMD using the longest diagonal
- (0.4µm MMD. measured aerodynamically), complying with EN143 EN13274-7
Run Time
- 6 hours per solution charge
Solution
- 1% Na Cl 10g/l
Solution Charge
- Approx: – 600 ml for 1.0 liter reservoir
- 100 ml for 0.5 liter reservoir
Calibration
- Certification by SFP Services prior to dispatch
